Product Overview
GE 20023 Constant Color 70W-T6 4200K-G12 Ansi M139 Pulsearc Ceramic Metal Halide Tubular Lamp
- CRI 91
- UV Control
- Rated Volts 90
- Lamp Wattage 70W.
- Bulb Designation T6
- Burn Position Universal
- Rated Life 15,000
- Initial Lumens 6,300
- Color Temp CCT 4200K
- Max. Base Temp. 250º
- Max. Bulb Temp. 400º
- LCL 30mm ± 2mm
- MOL 3.56in x DIA 0.86
- UPC #043168200233
- Universal Burn Position
- Base Type G12 Ceramic Bi-Pin
- Fixture Requirement Enclosed
- Max. Fixture Voltage-Rise 5 Volts
- Ballast Requirement ANSI M139,C139
- M98/E,M85/E (Enclosed Fixture Only)
- Made In Hungary
- Spec Sheet
Additional Information
- Highly efficient Reduce energy costs by $33.00-$260.00 per lamp*
- 4 times more lumens per watt than comparable incandescent or halogen lamps
- for color-critical applications such as retail display Excellent color rendering Up to 90 CRI
- for setting the desired look for the application.
- Long life Up to 16,500 hour rated life provides for extended relamp cycles and reduced maintenance costs
- Point source of light Compact quartz envelope allows for terrific fixture optics to maximize system efficiency
- Replacement 70W M139 Ballast & G12 Sockets Available
Cross Refernence
- Philips MasterColor CDM-T6 70W/942 G12
- Osram HCI-T 70/ NDL G12
- Sylvania MC70T6/U/G12/940
- ILCOS MT/UB-70/40/1B-H/E-G12-13/57
R Warning:
This lamp can cause serious skin burn and eye inflammation from shortwave ultraviolet radiation
if outer envelope of the lamp is broken or punctured, and the arc tube continues to operate.
Do not use where people will remain for more than a few minutes unless adequate shielding
or other safety precautions are used. Certain types of lamps that will automatically
extinguish when the outer envelope is broken or punctured are commercially available.
